| Engine type |
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine |
| Bore x stroke [mm] |
78x62 |
| Displacement [ml] |
296 |
| Engine speed [rpm] |
3000/3600 |
| Compression ratio |
20:01 |
| Rated output power [KW (Hp)] |
3.7 (5.03)/3000 |
| Rated output power [KW (Hp)] |
4.0 (5.44)/3600 |
| Fuel |
0# or - 10# light diesel oil |
| Fuel tank volume [L (gal.)] |
3.5 (0.77) |
| Fuel consumption rate [g(ml)/KW.h] |
283 (337) |
| Lubrication oil volume [L (gal.)] |
1.1 (0.24) |
| Power-Take-Off |
Crankshaft |
| Starting system |
Recoil or electric |
| Overall dimension (LxWxH) [mm] |
480x460x520 |
| Dry weight [kg (lbs.)] |
33 (72.6) recoil 38 (83.6) electric |
|
