| Suction, discharge port diameter [mm (in)] |
80 (3.0) |
| Discharge capacity [m3/h] |
13 |
| Total head lift [m (ft)] |
26 |
| Max suction head [m (ft)] |
8 (26.25) |
| Rotation speed [rpm] |
3600 |
| Priming time [s/4m] |
40 |
| Overall dimension (LxWxH) [mm] |
525x410x480 |
| Dry weight [kg] |
36 |
| Engine model |
SU200 |
| Rated power [KW (Hp)] |
3.7 (5.03) |
| Rated rotation speed [rpm] |
3600 |
| Fuel tank capacity [L (gal.)] |
3.5 (0.77) |
| Fuel consumption [g/KW.h] |
230 |
|
