| Suction, discharge port diameter [mm (in)] |
50 (1.97) |
| Discharge capacity [m3/h] |
22 |
| Total head lift [m (ft)] |
26 (85.3) |
| Max suction head [m (ft)] |
8 (26.25) |
| Rotation speed [rpm] |
3600 |
| Priming time [s/4m] |
80 |
| Overall dimension (LxWxH) [mm] |
475x385x455 |
| Dry weight [kg] |
25 |
| Engine model |
SU168 |
| Rated power [KW (Hp)] |
2.5 (3.4) |
| Rated rotation speed [rpm] |
3600 |
| Fuel tank capacity [L (gal.)] |
3.5 (0.77) |
| Fuel consumption [g/KW.h] |
285 |
|
