| Model |
Greenhouse Wang |
| Engine Model |
TY2100T |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
100X105 |
| RATED POWER[KW(HP)] |
18.4 |
| RATED SPEED(RPM) |
2350 |
| Calibration conditions fuel consumption rate g/kW·h |
≤248.9 |
| Types |
Front：4.00-12 Wheel：7.50-16 |
| Front-wheel tread mm |
970 |
| Rear-wheel tread mm |
980 |
| Wheelbase mm |
1475 |
| RATED TRACTION FORCE(N) |
5200 |
| PTO SPEED(rpm) |
|
| Speed km/h |
1.37-26.40 |
| Gearbox few stalls |
（3+1）×2 Or （4+1）×2 |
| GROUND CLEARANCE(MM) |
190 |
| OVERALL Dimensions mm |
2447×1240×1050 |
| MIN.USE WEIGHT kg |
1120 |
|
