| Model |
164Y Tractor |
| EngineModel |
3C093 |
| Engine |
3 CYLINDER,WATERCOOLED,VERTICAL,4 STROKE DIESEL |
| RATED POWER[KW(HP)] |
11.76 |
| RATED SPEED(RPM) |
2400 |
| Types |
Front ：5.00-12 Rear ：7.50-16 |
| Front-wheel tread mm |
980/970-1270 |
| Rear-wheel tread mm |
740-780 |
| Wheelbase mm |
1260 |
| RATED TRACTION FORCE(N) |
3900 |
| PTO SPEED(rpm) |
540 Or 760/1000Double Speed |
| Speed km/h |
1.32-13.92 |
| Gearbox few stalls |
(3+1)2 |
| GROUND CLEARANCE(MM) |
245 |
| OVERALL Dimensions mm |
2055×945×1180 |
| MIN.USE WEIGHT kg |
580 |
|
