| Model |
204 Tractor |
| Engine Model |
Y380/LL380 |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
90×100 |
| RATED POWER[KW(HP)] |
14.72 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤260 |
| Types |
Front：6.00-12 Wheel：8.3-24 |
| Front-wheel tread mm |
1000 |
| Rear-wheel tread mm |
920-1380 |
| Wheelbase mm |
1645 |
| RATED TRACTION FORCE(N) |
4800 |
| PTO SPEED(rpm) |
540，720 Or 540/720 Or 540/1000 |
| Speed km/h |
0.24-24.75 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
275 |
| OVERALL Dimensions mm |
2946×1235×1300 |
| MIN.USE WEIGHT kg |
1100 |
|
