| Model |
200 Tractor |
| Engine Model |
Y380/LL380 |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
90×100 |
| RATED POWER[KW(HP)] |
14.72 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤260 |
| Types |
Front：4.00-16 Wheel：8.3-24 |
| Front-wheel tread mm |
970 / 970-1270 |
| Rear-wheel tread mm |
900-1020 |
| Wheelbase mm |
1470/1530 |
| RATED TRACTION FORCE(N) |
4000/4600 |
| PTO SPEED(rpm) |
540/720 |
| Speed km/h |
1.53-29.41 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
330 |
| OVERALL Dimensions mm |
2886/2946×1235×1288 |
| MIN.USE WEIGHT kg |
1050 |
|
