| Model |
400A Tractor |
| EngineModel |
TY3102 |
| Engine |
Triplex, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
102X105 |
| RATED POWER[KW(HP)] |
29.4 |
| RATED SPEED(RPM) |
2300 |
| Calibration conditions fuel consumption rate g/kW·h |
≤243 |
| Types |
Front ：6.00-16 Rear ：11.2-28 |
| Front-wheel tread mm |
1050-1450 |
| Rear-wheel tread mm |
1150-1450 |
| Wheelbase mm |
7000 |
| RATED TRACTION FORCE(N) |
8810 |
| PTO SPEED(rpm) |
540/720 |
| Speed km/h |
2.09-28.34 |
| Gearbox few stalls |
（3+1）×2 Or （4+1）×2 |
| GROUND CLEARANCE mm |
355 |
| OVERALL Dimensions mm |
3090×1450×1954 |
| MIN.USE WEIGHT kg |
1483 |
|
