| Model |
604 Tractor |
| EngineModel |
YTR4105T |
| Engine |
4 cylinder, vertical, water-cooled, 4 stroke DIESEL |
| Bore x itinerary mm |
105X110 |
| RATED POWER[KW(HP)] |
44.1(60) |
| RATED SPEED(RPM) |
2300 |
| Calibration conditions fuel consumption rate g/kW·h |
≤257 |
| Types |
Front ：8.3-20 Rear ：13.6-28 |
| Front-wheel tread mm |
1450 |
| Rear-wheel tread mm |
1350-1650 |
| Wheelbase mm |
2060 |
| RATED TRACTION FORCE(N) |
1550 |
| PTO SPEED(rpm) |
540.720.1000中任选两种 |
| Speed km/h |
0.363-34.200 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE mm |
340 |
| OVERALL Dimensions mm |
3942X1675X2485 |
| MIN.USE WEIGHT kg |
2450 |
|
