| Model |
504 Tractor |
| EngineModel |
495BT |
| Engine |
Four-cylinder, vertical, water-cooled, four-stroke |
| Bore x itinerary mm |
100X110 |
| RATED POWER[KW(HP)] |
40-65 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤248.9 |
| Types |
Front ：4.00-12 Rear ：7.50-16 |
| Front-wheel tread mm |
1300 |
| Rear-wheel tread mm |
1300-1600 |
| Wheelbase mm |
2010 |
| RATED TRACTION FORCE(N) |
13000 |
| PTO SPEED(rpm) |
540/720(1000)Double Speed |
| Speed km/h |
1.37-26.35 |
| Gearbox few stalls |
（3+1）×2 Or （4+1）×2 |
| GROUND CLEARANCE mm |
325 |
| OVERALL Dimensions mm |
3890×1625×2065 |
| MIN.USE WEIGHT kg |
2116 |
|
