| Model |
500 Tractor |
| EngineModel |
SL4100BT |
| Engine |
Four-cylinder, vertical, water-cooled, four-stroke |
| Bore x itinerary mm |
100X115 |
| RATED POWER[KW(HP)] |
36.8 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤257 |
| Types |
Front ：6.00-16 Rear ：12.4-28 |
| Front-wheel tread mm |
1250-1500 |
| Rear-wheel tread mm |
1300-1600 |
| Wheelbase mm |
1944 |
| RATED TRACTION FORCE(N) |
10400 |
| PTO SPEED(rpm) |
540/720(1000)Double Speed |
| Speed km/h |
0.32-30.2 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
370 |
| OVERALL Dimensions mm |
3890×1830×2020 |
| MIN.USE WEIGHT kg |
1890 |
|
