| Model |
400B Tractor |
| EngineModel |
SL3105BT/490BT |
| Engine |
3/4 cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
105X110 |
| RATED POWER[KW(HP)] |
29.4(40) |
| RATED SPEED(RPM) |
2200/2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤228 |
| Types |
Front ：6.00-16 Rear ：11.2-28 |
| Front-wheel tread mm |
1250-1550 |
| Rear-wheel tread mm |
1300-1600 |
| Wheelbase mm |
1877.5 |
| RATED TRACTION FORCE(N) |
8200 |
| PTO SPEED(rpm) |
540/720(1000)Double Speed |
| Speed km/h |
0.307-28.923 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE mm |
345 |
| OVERALL Dimensions mm |
3825×1830×2020 |
| MIN.USE WEIGHT kg |
1886 |
|
