| Model |
1104 Tractor |
| Engine Model |
LR6105T79 |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
105X125 |
| RATED POWER[KW(HP)] |
80.9 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤248.9 |
| Types |
front：14.9-24 wheel：16.9-38 |
| Front-wheel tread mm |
1808-2148(1912) |
| Rear-wheel tread mm |
1664-2268(1664) |
| Wheelbase mm |
2689 |
| RATED TRACTION FORCE(N) |
24000 |
| PTO SPEED(rpm) |
720 |
| Speed km/h |
2.15-28.15 |
| Gearbox few stalls |
（3+1）×4 |
| GROUND CLEARANCE(MM) |
470 |
| OVERALL Dimensions mm |
4800×2330×2980 |
| MIN.USE WEIGHT kg |
4500 |
|
