| Model |
1004B Tractor |
| Engine Model |
LR6105T79 |
| Engine Type |
6-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x stroke mm |
105X125 |
| Rated Power [KW(HP)] |
80.9 |
| Rated Speed (RPM) |
2400 |
| Fuel Consumption g/kW·h |
≤248.9 |
| Types |
front：14.9-24 wheel：16.9-38 |
| Front-wheel Tread(mm) |
1808-2148(1912) |
| Rear-wheel tread (mm) |
1664-2268(1664) |
| Wheelbase mm |
2689 |
| Rated traction Force (N) |
24000 |
| PTO Speed(rpm) |
720 |
| Speed km/h |
2.15-28.15 |
| Gearbox |
（3+1）×4 |
| Ground Clearance(mm) |
470 |
| Overall Dimensions mm |
4800×2330×2980 |
| Min.Use Weight (kg) |
4500 |
|
