| Model |
WP15DC/4HP |
| Suction port diameter [mm (in)] |
40(1.5) |
| Discharge port diameter [mm (in)] |
40(1.5) |
| Discharge capacity [m3/h] |
18 |
| Max head lift [m] |
60 |
| Max suction head [m] |
7 |
| Rotation speed [rpm] |
3600 |
| Engine model |
SU170F/E |
| Rated power [Hp] |
4 |
| Displacement [ml] |
211 |
| Starting system |
RECOIL STARTER/ELECTRIC STARTER |
| Fuel tank capacity [L] |
2.5 |
| Overall dimension (LxWxH) [mm] |
520x440x550 |
| Dry weight [kg] |
42 |
|
