| Model |
WP40DC/20HP |
| Suction port diameter [mm (in)] |
100(4) |
| Discharge port diameter [mm (in)] |
100(4) |
| Discharge capacity [m3/h] |
120 |
| Max head lift [m] |
85 |
| Max suction head [m] |
7 |
| Rotation speed [rpm] |
3600 |
| Engine model |
2V86 |
| Rated power [Hp] |
20 |
| Displacement [ml] |
840 |
| Starting system |
RECOIL STARTER/ELECTRIC STARTER |
| Fuel tank capacity [L] |
5.5 |
| Overall dimension (LxWxH) [mm] |
850x550x750 |
| Dry weight [kg] |
95 |
|
